Hydraulic Wire Rope Tower Crane Winch For Architectural Engineering
| product name | hydraulic winch |
| Usage | tower crane ,offshore platform |
| Winch drum type | suggest LBS (smooth or traditional spiral ) |
| Fuction | lifting,hoist,pulling |
| Field | offshore,crane ,marine,oil drilling,mining |
| Wire rope diameter | 3~199mm |
| Wire rope capacity | 100-1000M |
| Colour | red or customer |
| Orignal | China(mainland) |
| Load capacity | 1-60KN |
| Rope speed | 0-40m/min |
| Power | hydraulic or customer |
Pay more attention to your choose:
We suggest your choose the LBS drum design .As it can save time and money for your in the future use .As the LBS design have its specail design for two parallel and two spiral lsection in one layer that can make the rope on its regular track and working smoothly than the traditional design .That can improve your working efficency.
Some products type parameter for your reference:that can be design to meet requirement
| Model | Layer plly force (T) | Rope speed | Drum bottom diameter | Difference of working pressures(Mpa) | Rope capaticty(mm) | Diameter of steel cable(mm) | Model of power |
| LBSTC1-10 | 30 | 0-35 | 305 | 15.9 | 65 | 15 | XH2-420 D51 |
| LBSTC1-20 | 50 | 0-40 | 380 | 16.3 | 70 | 20 | XH3-900 D240 101 |
| LBSTC1-30 | 80 | 0-40 | 470 | 15.6 | 100 | 24 | XH5-1800 D240101 |
| LBSTC1-40 | 100 | 0-40 | 470 | 16 | 90 | 28 | XH6-2000 D240 101 |
| LBS0F1-50 | 120 | 0-30 | 600 | 17.3 | 175 | 30 | XH6-3000 D240101 |
| LBSTC1-60 | 150 | 0-30 | 640 | 17.8 | 143 | 38 | XH7-4300 D240101 |
| LBS TC1-70 | 200 | 0-25 | 660 | 17.8 | 150 | 40 | XH8-900d240101 |
Product specification:
Custom-made (according to actual )
Product application:
It is widely used in port, workshop, warehouse, construction and many kinds producing-line, so is necessary equipment for lifting goods, raising labor efficiency, improving working conditions.
Product structure:
Hydraulic winch is usually combined with hydraulic motor, control valves, gear boxes, grooved drum, brackets (clutch), pressure rope and mounting brackets.
Product Feature:
1) Two-or three-stage planetary gearboxes, smooth operation and reasonable structure.
2) High efficiency of starting and transmissing, low energy consumption, reliable operation and long service life.
3) Highly efficient, constant operating torque motor.
4) Smooth running over the entire speed range.
5) Axial fixed or variable hydraulic motor with long life operating.
6) Mounting frame is available on request.
7) Low noise operation.
Product advantage:
Our factory mainly in the service of hoisting machinery, Marine machinery, petroleum machinery, hydraulic machinery, engineering machinery and other industries, the main products are oil drilling rig, workover rig, drifting machine, trailermounted pumping unit winch (The main drum is used LBS grooved drum) and oil equipment accessories.
